How to use a side seam stitching machine?

An Shoe sole side stitching machine is called shoe border sewing machine, it is a swing arm sewing machine specifically designed for footwear manufacturing. It's primarily used for connecting the side seams between the upper and sole of shoes, creating exposed stitches (exposed stitches). Commonly found in athletic shoes, casual shoes, and other footwear types. These machines typically use lockstitch and feature double-thread or double-needle designs to enhance stitch strength and aesthetics. Out sole side seam machines are widely used in the later stages of shoe manufacturing, especially suitable for mass production of shoes requiring high-strength side seams. They offer high sewing efficiency and can adapt to different materials for uppers and soles.

Main Features and Functions

Stitch Type: 301 type lockstitch flatbed sewing machine, producing clear and strong stitches, suitable for decorative sewing.

Operation Method: Mostly semi-automatic or fully automatic, supporting foot pedal or electric drive; some models are equipped with electronic speed control and computer-controlled needle stop functions.

Application: Specifically designed for side seam processing of uppers and soles, with a sewing thickness generally in the range of 1.5-6 mm.

Typical Models: Such as TOPEAGLE TSH-2168, commonly found in athletic shoe production lines.

Safe Operation and Preparation: Before operation, ensure the power supply voltage is compatible (e.g., single-phase 220V or three-phase 380V) and check the grounding reliability. The equipment should be placed on a stable, well-ventilated workbench, away from flammable materials. After first use or long-term inactivity, check the lubrication points and add the specified lubricant. Also, confirm that consumables such as sewing thread and needles (e.g., CP5 model) are readily available.

Basic Operating Steps:

Threading and Adjusting: Thread the thread through the spool, thread guide, and needle according to the internal guide wire path of the sewing machine to form a lockstitch. The bobbin thread must be correctly wound onto the bobbin and loaded into the bobbin bed. An automatic threader simplifies threading.

Sewing Settings: Adjust the presser foot pressure and stitch length (3-13mm) according to the fabric thickness (1.5-6mm); set the sewing speed using the electronic speed control knob; low speed is suitable for thicker materials or side seams.

Start Sewing: Place the fabric and press down the presser foot to secure it; slowly depress the foot pedal to start the sewing machine, ensuring a smooth fabric feed; when sewing side seams, control the feed dog and needle plate to prevent fabric skewing.

Maintenance and Troubleshooting: After daily use, clean the needle plate and shuttle bed of loose threads and dust. Regularly check the wear of belts and gears. Common problems such as skipped stitches require checking if the needle is bent or the stitch tension is appropriate. Uneven stitches can be addressed by adjusting the feed dog height or replacing the needle.

Precautions: Do not place your fingers near the needle or feed mechanism during operation; always turn off the power and unplug the machine when changing needles or performing maintenance; if the equipment makes abnormal noise or vibrates, stop the machine immediately and inspect it.
